Description
HCP-W(SCI) Weatherproof Addressable Call Point with SCI (Red)
Manufactured by Hochiki, this Hochiki HCP-W (SCI) Weatherproof Addressable Call Point with SCI (RED) is a weatherproof Manual Call Point with integral short-circuit isolator, which is fully compatible with Hochiki’s ESP analogue addressable protocol.
The unit incorporates a bi-coloured LED, which can be selected as pulsing/non-pulsing for communications polling and is continuously lit when the HCP-W(SCI) is operated – in these two states the LED will show red. The LED will show amber when a short-circuit is present but will switch to red if the unit is activated. The unit operates by pressing the EN54 compliant non-frangible (plastic) element and produces a high level ESP interrupt.
A built in test function initiated by the control panel ensures the integrity of the device at all times and the device can be tested by insertion of a test key in the underside of the unit. Two terminal blocks are provided for easy connection to the loop wiring. The unit is addressed using the TCH-B200 Hand Held Programmer.
Product Details:
Manufacturer: Hochiki
Part Number: HCP-W (SCI)
Key Features:
- Fast response
- Integral short-circuit isolator
- Bi-coloured status LED
- Non-frangible element fitted as standard (conforms to EN54)
- Addressed with TCH-B200 Hand Held Programmer
- Surface mounted
- IP67 rated
- LPCB approved to EN54
 |
Product Specification PDF |
