Description
Manufactured by Morley, this Morley IAS DXC Compact Mimic Driver 020-909 provides 16 LED outputs, common fire, fault, test, disablement and power OK output. Accepts keyswitch inputs to enable evacuate, silence, lamp test, mute and reset. Connects directly to the RS485 port provided as standard on the DXc panels. Expandable with up to 9 additional expansion mimic boards each providing 16 additional outputs. (020-910). Requires 24 Vdc.
The DXc Compact Mimic allows geographic ‘floor map’ zonal indicators to be built for situations where increased clarity of the fire location is required above that given by standard numbered zonal indicators.
The Compact Mimic is an expandable system suitable for ‘standard’ or more complex applications where mimic displays are required in association with DXc fire control panels.
The Compact Mimic main board (020-909) can display General Fault, General Disablement, Power OK (Mimic’s own power status), General Fire, Test, Communication Fail state, 16 LED’s or relay outputs configured to follow the fire and fault status and has provision for Evacuate, Silence Sounders, Lamp Test, Mute Buzzer and Reset pushbuttons and for a level 2 access key switch.
Morley IAS DXC Compact Mimic Driver 020-909 product specifications / product detail are as follows:
Manufacturer: Morley
Part Number: 020-909
