Description
This unit is the same as the basic 30621 detector, but contains a large dot matrix graphic
display, capability of single point programming and set-up for entire connected
system (max 127 devices) or connection to SenseNET computerbased
information centre for detection system.
The Stratos-HSSD2 has unmatched sensitivity potential, providing the very earliest warning
of incipient fire with a minimal rate of nuisance alarms.
of incipient fire with a minimal rate of nuisance alarms.
The Stratos-HSSD2 employs a patented Artificial Intelligence system known as ClassiFire,
which ensures that the detector operates at optimum sensitivity for the protected environment,
without the need for complex setup.
which ensures that the detector operates at optimum sensitivity for the protected environment,
without the need for complex setup.
The unit is equipped with 'Fault' and four 'Alarm' relays,
plus three programmable remote control inputs. Relay outputs provide a convenient method
for remote monitoring by local fire alarm panels or building management systems.
plus three programmable remote control inputs. Relay outputs provide a convenient method
for remote monitoring by local fire alarm panels or building management systems.
Open Protocol is available for 3rd party integration.
Addressable Protocol interface cards are available for various manufacturers' fire panels.
Features
Affordable, feature-rich aspirating smoke detector.
Industry's widest sensitivity range provided by laser-based forward light scatter mass detection with particle evaluation.
Four sampling pipes, up to 820 ft total length covering up to 20,000 sq. ft.
Up to 100 sample ports.
Unique ClassiFire® Perceptive Artificial Intelligence system that dynamically adjusts the detector's operating parameters.
Dual technology laser dust discrimination and elimination system.
RS485 and RS232 communications built in as standard for networking, remote communications and PC configuration.
Rugged steel enclosure option available. Suitable for industrial environments.
Addressable Protocol interface cards are available for various manufacturers' fire panels.
Features
Affordable, feature-rich aspirating smoke detector.
Industry's widest sensitivity range provided by laser-based forward light scatter mass detection with particle evaluation.
Four sampling pipes, up to 820 ft total length covering up to 20,000 sq. ft.
Up to 100 sample ports.
Unique ClassiFire® Perceptive Artificial Intelligence system that dynamically adjusts the detector's operating parameters.
Dual technology laser dust discrimination and elimination system.
RS485 and RS232 communications built in as standard for networking, remote communications and PC configuration.
Rugged steel enclosure option available. Suitable for industrial environments.
